Harvest Pro - HP5

The industry's only single-row plot harvester.

In a class of its own, the HP5 is the world's only one-row, multi-crop combine. Its compact size and light weight provides maximum maneuverability and easy trasportation. The HP5 is specifically designed to harvest up to 30,000 single-row plots per season. Multiple sample handling configurations are available to meet your research requirements.

Financing and leasing options available.

Contact a Rep or call: (515) 382-3506

  • One person operation
  • Deutz air-cooled diesel engine
  • Standard Platform Header, Single Row-Row Crop Header, or Single Row Corn Header
  • Electronics with Data Capture System
  • Weigh System Options
  • Hydraulic “fail safe” brakes
  • Discard seed options
  • Bulk seed organizer
  • Package seed storage bins with easy unload
  • Drive
    • Hydrostatic drive, forward and reverse
    • 40 h.p. Deutz air-cooled diesel engine
    • Large 11 gallon fuel tank
    • Power steering on rear wheels
    • Large super terra grip flotation drive tires; front tires 26 x 12 x 12, rear  tires 23 x 10.5 x 12
    • Hydraulic fail-safe brakes (4,000 series with Mico brakes)
  • Threshing
    • Variable speed, mechanically driven threshing cylinder, 13.25” diameter x 17.5” wide, with eight metal raspbars
    • Underslung, self-cleaning concave, quick adjust
    • Winnowing blower for seed cleaning
    • Air column seed separation system
  • Seed Handling
    • One-person operator’s platform
    • Fully pneumatic seed delivery to driver
  • Miscellaneous
    • All controls conveniently located on operator’s console
    • Safety cover guards on moving parts
    • Hydraulic header height control with float position
    • Length: 14’ with head
    • Width: 45”
    • Weight: 4,200 lbs with head
